Description
Knox ASW LT-G2 33kW On-Grid Solar Inverter
The Knox ASW LT-G2 33kW On-Grid Solar Inverter is a reliable and high-performance inverter designed for medium to large commercial solar installations. With multiple MPPT inputs, wide voltage range, and high power output, it optimizes energy production from solar systems while ensuring efficiency and longevity.
Key Features
- Communication Interface: Supports Wi-Fi, 4G, and RS485 for real-time monitoring and management of the solar system.
- Degree of Protection: IP65 rated for dust and water resistance, making it ideal for outdoor and harsh environments.
- Max PV Array Power: Capable of handling a maximum solar array power of 37,500Wp, ensuring maximum energy conversion efficiency.
- Multiple MPPT Inputs: Features 2 independent MPPT inputs, allowing for flexible energy harvesting from different parts of the system.
- Wide MPPT Voltage Range: Voltage range from 150V to 1000V with a rated input voltage of 630V, providing versatility in system design.
- High Power Output: Delivers a rated power of 33,000W for optimal performance in medium to large-scale solar installations.
- Compact Design: Measures 50.3 x 18.3 x 43.5 cm and weighs 18.6 kg, making it easy to install and integrate into various systems.
The Knox ASW LT-G2 33kW On-Grid Solar Inverter is engineered to maximize the energy efficiency of commercial solar systems while providing reliable, flexible, and safe operation in various conditions.
| FEATURES | |
| Communication Interface 1 & 2 | Wi-Fi / 4G / RS485 |
| Country of Manufacture | China |
| General specifications | |
| Degree of Protection | IP65 |
| Dimensions | 50.3 x 18.3 x 43.5 cm |
| Weight | 18.6 kg |
| Input (DC) | |
| AC Nominal Voltage | 220V/380V – 230V/400V – 240V/415V |
| Max PV Array Power | 37500Wp |
| Max Short Circuit Current | 60A / 48A |
| MPPT Voltage Range/Rated Input voltage | 150V to 1000V/630V |
| Number of Independent MPPT Inputs/Strings per MPPT Input | 2/A:2:B:2 |
| Rated Power | 33000W |
Additional information
| Manufacturer | Knox |
|---|
